Specification
|
Model |
XPN-DSA8650 (ISDB Digital) |
|
Operating System |
Android TV 11; Google Play |
|
Preinstalled Apps |
Google Play, Google Assistant, Chromecast |
|
Panel size |
86″Wide |
|
Aspect ratio |
16:9 |
|
Viewing angle |
H:178°/V:178° |
|
Max.resolution |
3840*2160 Ultra HD Resolution |
|
Display color |
1.07b |
|
Max. brightness |
Min.:350cd/m2;Typ.400cd/m2 |
|
Max. contrast ratio |
1200：1 ; Dynamic contrast ratio |
|
HDR |
HDR10 |
|
Response time |
8ms |
|
Input signal |
3 x HDMI 2.0 (HDCP 2.2); 2 x USB Ports, AV In, RJ45 Port, HDMI-ARC, HDMI-CEC |
|
Output Signal |
Coaxial-OUT/SPDIF Out Optical |
|
CPU |
ARM Cortex-A55 ; Mali-G52 MC1 ; 2GB DDR RAM, 16GB Storage |
|
Power consumption |
≤ 380W |
|
Operating voltage |
100V-240VAC 60/50Hz |
|
Audio Power output |
10W×2; Dolby Audio |
|
Bluetooth |
Bluetooth 5.1 |
|
Wireless |
Wi-Fi AC Connectivity: 2.4G/5G Wireless T2TR |
|
USB |
support:Video/Audio/Image |
|
Size L×W×H |
Size (carton) L×W×H 12080×220×1280mm; 56.1kg Size (with stand) L×W×H 1924×441×1182mm; 43.4kg Size (Wall Mount Hole) 600*400mm |
|
Working Environment |
Temperature：5℃～40℃ humidity：20%～80% atmosphere：86KPa～106KPa |
|
Storage Environment |
Temperature：-20℃～55℃ humidity：20%～80% atmosphere：86kPa～106kPa |
|
Warranty |
Standard 2 Years Warranty on Parts and Labor |
Services
Standard Warranty and Service Offerings
|
Downloads
| Title | Date | Filename | |
| Product Brochure Data Sheet OS: Adobe Acrobat Reader | Jan 2023 | XPN-DSA8650-ANDROID.PDF |
Download |
