Technical Specification |
|
Model |
XPN-GX25F280 |
Panel Size (diagonal) |
24.5" Diagonal |
Panel Backlight |
ELED edge Type, Fast IPS Panel |
Display Surface |
Non-glare |
Color Gamut(NTSC) |
72% NTSC; 99% sRGB |
Maximum resolution |
1920 x 1080 (Full HD) |
Refresh Rate (Max.) |
280Hz |
Brightness (Max.) |
350cd/m2 |
Contrast Ratio (Max.) |
1000 : 1 (TYP.) Dynamic Contrast Ratio |
Viewing Angle |
H:178º,V:178º(CR≥10) |
Display Colors |
16.7M colors |
Response Time |
1ms MPRT |
Signal Input |
HDMI 2.0 x1 (1920x1080@240Hz) Display port 1.2 x1 (1920x1080@280Hz) speaker Jack; VESA Wall Mount |
Special Feature |
|
Flicker Free |
Supports Flicker Free ( Without causing eye strain and other injuries) |
Low blue Light |
Supports Low blue Light reduction |
HDR |
HDR 400 |
AMD Freesync |
Support AMD Freesync Technology |
nVidia G- Sync |
Support nVidia G-Sync Technology |
Power Management |
|
Power input |
12V/4A |
Working consumption |
≤40W typical |
Standby consumption |
≤0.5W |
Audio power(Optional) |
2*3W |
Safety |
|
Withstand voltage strength |
≤3.5mA @2.5KV DC/60S |
Leakage current |
≤3.5mA @264V AC/60S |
Earthing protective resistance |
≤100mΩ |
Working condition |
Temperature:5℃~40℃ humidity:10%~85% atmosphere:86KPa~104KPa |
Storage condition |
Temperature:-20℃~55℃ humidity:5%~95% atmosphere:86kPa~104kPa |
Dimension |
611.3x362.3x88mm w/out base; 611.3x462.4x251.8mm with Base; net weight 4.8 Kg,gross weight 6.5 Kg |
Warranty |
3 Years Standard Warranty |
