Configuration
|
Specification
Supported Processors |
Intel® Core™ i7-1255U Processor 12M Cache, up to 4.70 GHz ( 10 Cores and 12 Threads) Intel® Core™ i5-1235U Processor 12M Cache, up to 4.40 GHz ( 10 Cores and 12 Threads) Intel® Core™ i3-1215U Processor 10M Cache, up to 4.40 GHz ( 6 Cores and 8 Threads) |
Display Size |
Narrow Bezel 15.6”(35.62cm) FHD(1920x1080) 16:9 panel, 3.2mm |
Operating System |
Microsoft® Windows® 11 Home or Professional 64bit; Supports Windows 10 |
System Memory |
Two 260 pins SODIMM sockets, support DDR4 3200MHz; Up to 64GB system Memory |
Storage |
One changeable 2.5” 7.0mm(H) HDD / SSD, SATA interface (Support 36WH Battery only) One M.2 2280 SSD, PCIe Gen4x4 interface (Support 36WH / 49WH Battery) |
Graphics |
Intel® Iris® Xe Graphics (i7-1255U / i5-1235U Processor) Intel® UHD Graphics (i3-1215U / 7305U / 8505 Processor) Rec. 2020 (Wide Color Gamut); Microsoft DirectX® 12 compatible |
Connectivity |
Built in 10/100/1000Mb Base-TX Ethernet LAN Built in Intel® Dual Band Wi-Fi 6E AX211 2x2 AX + Bluetooth 5.3; CNVi M.2 2230 (Factory Option) LTE M.2 module 3042 Built in 1.0M HD video camera; (Factory Option) 2.0M FHD camera with TNR (Temporal Noise Reduction) |
Audio |
• Sound Blaster™ Cinema 6+ High Definition Audio • Built in Array microphone, Built in two speakers(2W) |
Peripheral Interfaces |
• 1 x USB 2.0 port (Type A) • 1 x USB 3.2 Gen1 port (Type A), 1 x USB 3.2 Gen2 port (Type A) • 1 x USB 3.2 Gen2 port (Type C) or (Factory Option)1 x USB 3.2 Gen2 port with Display port with Power Delivery in (Type C) • 1 x HDMI™ output port (with HDCP) • 1 x 2-in-1 Audio Combo jack (Headphone + Microphone) • 1 x RJ-45 LAN port, 1 x DC-in jack, 1 x Micro SD Card Reader |
Keyboard and Pointing Device |
• Multi languages full size keyboard with numeric pad • (Option) Multi languages Multi-Color backlit keyboard with numeric pad • Built in Click pad with Microsoft PTP multi-gesture and scrolling function |
Power |
Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V 2.37A, 45W Embedded Polymer Smart Lithium-Ion battery pack, 36WH (Support 2.5” HDD/SSD and M.2 SSD) (Factory Option) Embedded Polymer Smart Lithium-Ion battery pack, 49WH (Support M.2 SSD) Battery life: 540 minutes (with 36WH battery) (TBC); Battery life: 680 minutes (with 49WH battery) (TBC) |
Dimension |
360.4(W) x 239.3(D) x 19.7(H)mm 1.59kg, Including 37WH Battery |
Pre install Software |
Microsoft Office 2019 Trial , Free Factory Installed Microsoft Security Essentials |
Standard Warranty and Service Offerings |
Service Offerings 1-Year Limited Parts Warranty & Technical Support Policy; 1-Year Next Business Day On-site Service |
Services
Standard Warranty and Service Offerings
|
Downloads
Brochure
Title | Date | Filename | |
E-500 12G Product Brochure Data Sheet OS: Adobe Acrobat Reader | Aug, 2022 | TravelPro-E500-12G.pdf | Download |
Drivers
Title | Date | Filename | |
E500 Product CHIPSET | Aug, 2022 | CHIPSET | Download |
E500 Product SERIAL IO | Aug, 2022 | SERIAL IO | Download |
E500 Product VIDEO | Aug, 2022 | VIDEO | Download |
E500 Product LAN | Aug, 2022 | LAN | Download |
E500 Product CARDREADER | Aug, 2022 | CARDREADER | Download |
E500 Product HIDFILTER | Aug, 2022 | HIDFILTER | Download |
E500 Product CC30 | Aug, 2022 | CC30 | Download |
E500 Product IME | Aug, 2022 | IME | Download |
E500 Product DPTF | Aug, 2022 | DPTF | Download |
E500 Product ANX | Aug, 2022 | ANX | Download |
E500 Product AUDIO | Aug, 2022 | AUDIO | Download |
E500 Product WIFI | Aug, 2022 | WIFI | Download |
E500 Product BT | Aug, 2022 | BT | Download |
E-500 Product RST | Aug, 2022 | IRST | Download |
