Features
![]() |
Configuration
|
Specification
Processors |
Support for 13th Gen Intel® Core™ i3, i5 and i7 processor series Support for 12th Gen Intel® Core™ i3, i5 and i7 processor series Supports Intel® Celeron™ Processor and Intel® Pentium™ Processor |
Core Chipset |
Intel® H610 Express Chipset |
Operating System |
Supports Microsoft Windows 11 Home and Professional; 64 bit |
System Memory |
Two DDR4 SDRAM Dual Inline Memory Module (SODIMM) sockets Support for up to DDR4 2666/2933/3200 MHz ; Support for up to 64 GB of system memory |
Graphics |
Integrated Intel® HD graphics engine |
Hard Drive |
Up to 4TB M.2 NVME SSD Up to 4TB SATA 6Gb/s SSD Solid State Drive Up to 4TB SATA 6Gb/s Hard Disk Drive Supports Dual Drive ( M.2 and 2.5inch) |
Media Storage |
Optional USB 8x DVD Writer Drive |
Audio |
Intel® High Definition Audio (Intel® HD Audio) |
Peripheral Interfaces |
Front Ports: Two Super Speed USB 3.0 front and Two USB 2.0 ports, 2x Audio Jack Ports, 1x Type C Port Rear Ports: Two USB 3.2 Gen 2x1 Type A port(s), 2 X USB2.0 port(s), 2 Audio Jack Ports (Line Out/Mic), 1 x HDMI 2.0 Port, 1 x VGA Port, 1 x RJ45 Port |
Monitors |
Choice of Xitrix® Branded Flat Panel LED Display |
Slots |
1 X PCI Express X16 Gen 4.0 slot(s); 1 X PCI Express X 1 Gen 3.0 slot(s); 1 X M.2 2242/2280 Storage Slot, 1 x M.2 2230 Slot for Wifi |
LAN Support |
(10/100/1000 Mb/s) LAN subsystem Gigabit Ethernet Controller Optional Intel® Dual Band Wi-Fi 6 AX201 2x2 AX + Bluetooth 5.2 |
Chassis Type Dimension Power Supply |
Xitrix DeskFrame 1L Tool Free Micro Chassis 179 x 37 x 183 mm Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 19V 2.1A, 90W |
Accessories |
Xitrix Ergonomic Design USB Business Keyboard and Mouse with Mouse Pad Vesa Mounting Kit, Optional Locking slot |
Standard Warranty and Service Offerings |
Service Offerings 3-Year Limited Parts Warranty & Technical Support Policy; 1-Year Next Business Day On-site Service Optional 3 Years Next Business Day on-site |
Services
Standard Warranty and Service Offerings
|
Downloads
Title | Date | Filename | |
E-310 Micro Product Brochure Data Sheet OS: Adobe Acrobat Reader | April 2023 | Deskframe-E-310 Micro.pdf | Download |
