Print Head / Ink
|
|
Number of Nozzles
|
Total 1,792 nozzles
|
|
Ink Bottles (Type / Colours)
|
GI-71, GI-71S (Bundled)
(Pigment Ink / Black),
(Dye-Based Ink / Cyan, Magenta, Yellow)
|
|
Maintenance Cartridge
|
MC-G04
|
|
Maximum Printing Resolution
|
4,800 (horizontal)*1 x 1,200 (vertical) dpi
|
|
Print Speed*2 (Approx.)
Based on ISO/IEC 24734
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions
|
|
Document (ESAT/Simplex)
|
11 / 6 ipm (mono/colour)
|
|
Document (FPOT Ready/Simplex)
|
9 / 14 sec (mono/colour)
|
|
Photo (4 x 6") (PP-201/Borderless)
|
45 sec
|
|
Printable Width
|
Up to 203.2 m (8")
Borderless: Up to 216 mm (8.5")
|
|
Print Margin
|
|
Borderless Printing
|
Top/Bottom/Left/Right margin: 0 mm
|
|
Bordered Printing
|
Envelopes (COM10, DL):
Top margin: 8 mm, Bottom margin: 12.7 mm
Left/Right margin: 3.4 mm
Envelopes (C5, Monarch)
Top margin: 8 mm, Bottom margin: 12.7 mm
Left/Right margin: 5.6 mm
B-Oficio, M-Oficio:
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 6.4 mm
LTR, LGL, Foolscap, F4, Oficio2
Top margin: 3 mm, Bottom margin: 5 mm
Left margin: 6.4 mm, Right margin: 6.3 mm
Legal (India)
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 5.9 mm
Square 5 x 5" (127 x 127 mm):
Top/Bottom/Left/Right margin: 6 mm
Square 3.5 x 3.5" (89 x 89 mm):
Top/Bottom/Left/Right margin: 5 mm
Custom Size:
Width 55 - 216 mm, Length: 89 - 1,200 mm
Top margin: 3 mm, Bottom margin: 5 mm
Left margin: 3.4 mm, Right margin: 3.4 - 9.4 mm
Others:
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 3.4 mm
|
|
Supported Media
|
|
Rear Tray
|
Plain Paper (64 - 105 g/m²)
High Resolution Paper (HR-101N)
Photo Paper Plus Glossy II (PP-201, PP-208)
Photo Paper Plus Semi-Gloss (SG-201)
Glossy Photo Paper (GP-508)
Photo Paper Pro Luster (LU-101)
Matte Photo Paper (MP-101)
Double Sided Matte Photo Paper (MP-101D)
Envelope
Photo Stickers (PS-208/PS-808)
|
|
Paper Size
|
|
Rear Tray
|
A4, A5, A6, B5, LTR, LGL, Executive, Oficio 2,
B-Oficio , M-Oficio, Legal (India), Foolscap, F4,
4 x 6", 5 x 7", 7 x 10", 8 x 10", Envelopes (DL, COM10, C5, Monarch), Square (89 x 89 mm, 127 x 127 mm), Card Size (91 x 55 mm)
[Custom Size]
Width: 55 - 216 mm
Length: 89 - 1,200 mm
|
|
Paper Size (Borderless)*3
|
A4, B5, LTR, 4 x 6", 5 x 7", 7 x 10", 8 x 10", Square (89 x 89 mm, 127 x 127 mm), Card Size (91 x 55 mm)
|
|
Paper Handling (Maximum Number)
|
|
Rear Tray
|
[Plain Paper (A4/LTR)]
Plain Paper (64 g/m²): 100
High Resolution Paper (HR-101N): 80
[Photo Paper, 4 x 6"]
Photo Paper Plus Glossy II (PP-201): 20
Photo Paper Plus Semi-Gloss (SG-201): 20
Glossy Photo Paper (GP-508): 20
Matte Photo Paper (MP-101): 20
Photo Paper Plus Glossy II (PP-208): 10
|
|
Paper Weight
|
|
Rear Tray
|
Plain Paper: 64 - 105 g/m²
Canon Paper: Max. 265 g/m²
(Photo Paper Plus Glossy II, PP-201)
|
|
Ink End Sensor
|
Dot count type
|
|
Print Head Alignment
|
Manual
|
Scan
|
Scanner Type
|
Flatbed
|
|
Scanner Method
|
Contact Image Sensor (CIS) |
|
Optical Resolution*5
|
600 x 1,200 dpi
|
|
Scanning Bit Depth (Input/Output)
|
|
Greyscale
|
16 bit / 8 bit
|
|
Colour
|
RGB each 16 bit / 8 bit
|
|
Line Scanning Speed*6 (Approx.)
|
|
Greyscale
|
1.5 ms/line (300 dpi)
|
|
Colour
|
3.5 ms/line (300 dpi)
|
|
Maximum Document Size
|
|
Flatbed
|
A4, LTR (216 x 297 mm)
|
Copy
|
Compatible Media
|
|
Size
|
A4, A5, A6, B5, LTR, Executive (184.2 × 266.7 mm), 4 x 6", 5 x 7", Square (127 x 127 mm), Card Size (91 x 55 mm)
|
|
Type
|
Plain Paper (64 - 105 g/m²)
Photo Paper Plus Glossy II (PP-201, PP-208)
Photo Paper Pro Luster (LU-101)
Glossy Photo Paper (GP-508)
Photo Paper Plus Semi-Gloss (SG-201)
Matte Photo Paper (MP-101)
|
|
Image Quality
|
3 positions (Economy, Standard, High) |
|
Density Adjustment
|
9 positions, Auto Intensity (AE copy)
|
|
Copy Speed*7 (Approx.)
Based on ISO/IEC 24734
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions
|
|
Document (Colour): (sFCOT/Simplex) / (sESAT/Simplex)
|
23 sec / 2.7 ipm
|
|
Multiple Copy
|
|
Mono/Colour
|
Max. 21 pages
|
|
Maximum Document Size
|
A4 / LTR
|
System Requirements
|
|
Windows 11 / 10 / 8.1 / 7 SP1
(operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)
macOS 10.14.6 – 12 or later
Chrome OS
|
General Specifications
|
Interface
|
USB 2.0
|
|
Operating Environment*9
|
|
Temperature
|
5 - 35°C
|
|
Humidity
|
10 - 90% RH (no dew condensation)
|
|
Recommended Environment*10
|
|
Temperature
|
15 - 30°C
|
|
Humidity
|
10 - 80% RH (no dew condensation)
|
|
Storage Environment*9
|
|
Temperature
|
0 - 40°C
|
|
Humidity
|
5 - 95% RH (no dew condensation)
|
|
Quiet Mode
|
Available
|
|
Acoustic Noise (PC Print) (Approx.)
|
|
Plain Paper (A4, Mono)*11
|
47.5 dB(A)
|
|
Power
|
AC 100 - 240 V, 50/60 Hz
|
|
Power Consumption (Approx.)
|
|
OFF
|
0.1 W
|
|
Standby (scanning lamp is off)
USB connection to PC
|
0.6 W
|
|
Copying*12
(USB connection to PC)
|
15 W
|
|
Duty Cycle
|
Up to 3,000 pages/month
|
|
Dimensions (WxDxH) (Approx.)
|
|
Factory Configuration
|
416 x 337 x 177 mm
|
|
Output / Trays Extended
|
416 x 557 x 268 mm
|
|
Weight (Approx.)
|
6 kg
|
|
Plain Paper (A4 pages)
(ISO/IEC 24712 test file)*13
|
Standard:
GI-71 PGBK: 6,000
GI-71 C, M, Y: 7,700*14
GI-71S PGBK: 3,100
GI-71S C, M, Y: 4,400*14
Economy*15:
GI-71 PGBK: 7,600
GI-71 C, M, Y: 8,100*14
GI-71S PGBK: 3,900
GI-71S C, M, Y: 4,600
|
Photo Paper (PP-201, 4 x 6")
(ISO/IEC 29103 test file)*13 |
Standard:
GI-71 PGBK: NA*16
GI-71 C, M, Y: 2,200
GI-71S PGBK: NA*16
GI-71S C, M, Y: 1,200 |
|
