Features
|
|
Configuration
|
•32” Ultra HD 4k Resolution
•Android 13 Google EDLA-Certified
•8GB RAM / 128GB Storage
•10point touch display
•9500mAh Built in battery
|
Specification
|
Model Name |
XPN-A32M5 |
|
Active Screen Size ("inch) |
32" |
|
Pixel Pitch |
0.06053(H)x0.18159(W) |
|
Display Ratio |
16:9 |
|
Resolution |
3840*2160 Pixel (4K) |
|
Display Colors |
8bit+FRC (1.07 billion color) |
|
LCD Brightness (Typical ,after cover class) |
min:400 cd/m²,Type:450cd/m² |
|
Contrast Ratio (Typical) |
4000:1 |
|
Response Time (Typical ,G to G) |
Type:6.5 ms Max：12 ms |
|
Viewing Angle |
178∘ |
|
Color Gamut |
72% NTSC |
|
System |
|
|
Android Operating System |
Android 13.0 Stable Operating System |
|
CPU |
8 Cores ARM Cortex-A76*4+ARM Cortex-A55*4 Working Frequency: ARM Cortex-A76:2.4GHz |
|
Graphics |
Mali-G610 MP4 |
|
System RAM |
8GB LPDDR4X |
|
System ROM Storage |
128GB ROM Storage |
|
General Specifications |
|
|
Power Supply |
90W 19V/4.74A |
|
Battery |
9500mAh/14.4V(136.8Wh) |
|
Battery charging time |
180min（Typ）/Play online videos |
|
Usage |
280min（Typ）/Play online videos |
|
Audio Output Power |
2x3W/4Ω |
|
Ports |
1 x HDMI 2.0 Port (4K@60Hz) 1x USB 2.0 Port 1x USB 3.0 Port |
|
Wireless |
Built in Wifi 6 2.4GHz/5GHz 802.11a/b/g/n/ac/ax Built in Bluetooth |
|
Structure |
|
|
Product Size |
731.31×23.7×426.23mm; 19kg |
|
Package Size |
1437×200×532mm ; 23kg |
|
Environment |
Operating temperature 0℃ ~ + 40℃. Storage humidity 0% ~ 60% RH Non-Condensing |
|
Warranty |
Standard 1 Year Warranty on Parts and Labor |
