Features
|
• Support Standard TFX form Factor • 350W Continuous power output at 40°C operating temperature • High efficiency with 80 PLUS Bronze • Silent running 80mm fan with 30 dBA minimum |
Specifications
| Model | XPN-IPT350W | |
| Type | TFX(175x85x65mm) | |
|
Output Currents For DC Inputs |
+3.3V | 15A |
| +5V | 15A | |
| +12V | 22A | |
| -12V | 0.5A | |
| +5VSB | 2.5A | |
| Input Voltage | 100-240 VAC | |
| Input Current | 8-4A | |
| Input Frequency | 50-60Hz | |
| PFC | APFC | |
| Power Good Signal | 100-150ms | |
| Hold Up Time | 8ms | |
| Efficiency | 87% | |
| MTBF | 100,000 hours | |
| Protection | OVP,UVP,OPP,OCP,SCP,SIP | |
| Maximum Wattage | 350W | |
| Cooling | 80mm Cooling Fan Black | |
| Operation Temperature | 0℃ to 40℃ | |
| Noise | 30-35 Db | |
| 80 Plus | Bronze | |
