DeskFrame™ E310 CFF

  • Sale
  • Regular price ₱20,800.00
  • Will be in stock after
Tax included.



Features
Featuring a compact form factor chassis, Xitrix DeskFrame E310 CFF features 12th Gen Intel Core Processors and supports up to 64GB of DDR4 System memory. Access important files and launch apps in a flash with the M.2 NVMe SSD slot. Discrete Graphics option from nVidia ensure immersive visuals. Plus, additional slots for RAM, storage, and PCIe expansion allow you to easily customize performance to your needs.


Configuration
  • Support 12TH Gen Intel® Core™ Series Processor
  • Up to 64GB DDR4 System Memory
  • Compact Form Factor Chassis
  • Up to 6GB Discrete Video Card
  • Energy Star Certified
  • Microsoft Windows 10 or 11 Operating System


Gallery



Specification

Processors

Support for 12TH Gen Intel® Core™ i3, i5 and i7 processor series

Supports Intel® Celeron™ Processor and Intel® Pentium™ Processor

Core Chipset

Intel® H610 Express Chipset

Operating System

Supports Microsoft Windows 10 Home and Professional; 64 bit; Supports Windows 11

System Memory

Two DDR4 SDRAM Dual Inline Memory Module (DIMM) sockets

Support for up to DDR4 2666/2933/ 3200 ; Support for up to 64 GB of system memory

Graphics

Integrated Intel® HD graphics engine

Optional Discrete Graphic Card

Hard Drive

Up to 14TB Serial ATA 6Gb/s Hard Drive

Up to 4TB M.2 NVME SSD

Up to 4TB SATA 6Gb/s SSD Solid State Drive

Supports Dual Drive ( 3.5inch and 2.5inch)

Media Storage

Optional 8x DVD Writer Drive; Built in Media Card Reader

Audio

Intel® High-Definition Audio (Intel® HD Audio)

Peripheral Interfaces

Front Ports: Two Super Speed USB 3.0 front and Two USB 2.0 ports, 2x Audio Jack Ports, 1x Type C Port

Rear Ports: 2 X USB 3.2 Gen 2x1 Type A port(s), 2 X USB2.0 port(s), 2x PS2 Ports, 3 Audio Jack Ports (Line Out/Line In/Mic In), 1 x HDMI 2.0 Port, 1 x VGA Port, 1 x Display Port, 1 x RJ45 Port

Monitors

Choice of Xitrix® Branded Flat Panel LED Display

Slots

1 X PCI Express X16 Gen 4.0 slot(s); 1 X PCI Express X 1 Gen 3.0 slot(s); 1 X M.2 2242/2280 Storage Slot, 1 x M.2 2230 Slot for Wifi

LAN Support

Integrated 10/100/1000 Gigabit LAN Port

Optional Intel® Dual Band Wi-Fi 6 AX201 2x2 AX + Bluetooth 5.2

Chassis Type

Dimension

Power Supply

Xitrix DeskFrame Compact Tool Free Chassis

320x 163x 285mm (15L Design)

300Watts High Efficiency 80Plus Power Supply; Optional 500watts Power Supply

Pre-installed

Microsoft Office 2019 Trial Version, Free Factory Installed Microsoft Security Essentials

Accessories

Xitrix Ergonomic Design USB Business Keyboard and Mouse (KM120) with Mouse Pad

Standard Warranty and Service Offerings

Service Offerings 3-Year Limited Parts Warranty & Technical Support Policy; 1-Year Next Business Day On-site Service

Optional 3 Years Next Business Day on-site




Services
 Standard Warranty and Service Offerings
  • Service Offerings 3-Year Limited Parts Warranty & Technical Support Policy; 1-Year Next Business Day On-site Service
    Optional 3 Years Next Business Day on-site


Downloads
Title Date Filename
E-310C Product Brochure Data Sheet OS: Adobe Acrobat Reader July 2022 Deskframe-E310-12G-CFF.pdf Download
E-310C Setup Guide Data Sheet OS: Adobe Acrobat Reader July 2022 Deskframe-E310-CFF_setup-guide.pdf Download
Driver Name OS (Operating System) Description
DeskFrame E310 Windows 10 64Bit Chipset Download
DeskFrame E310 Windows 10 64Bit ME Download
DeskFrame E310 Windows 10 64Bit LAN Download
DeskFrame E310 Windows 10 64Bit AUDIO Download
DeskFrame E310 Windows 10 64Bit VIDEO Download
DeskFrame E310 Windows 10 64Bit BIOS Download
