DeskFrame™ E300 (Promo)

  • Sale
  • Regular price ₱29,800.00
  • Will be in stock after
Tax included.



Features
Featuring a compact form factor chassis, Xitrix DeskFrame E300 features 11th Gen Intel Core Processors and supports up to 64GB of DDR4 System memory. Access important files and launch apps in a flash with the M.2 NVMe SSD slot. Discrete Graphics option from nVidia ensure immersive visuals. Plus, additional slots for RAM, storage, and PCIe expansion allow you to easily customize performance to your needs.


Configuration
  • Support 10th / 11th Gen Intel® Core™ Series Processor
  • Up to 64GB DDR4 System Memory
  • Supports Dual Drive configuration
  • Xitrix SFF Small Form Factor 8L Chassis / Xitrix CFF Compact Form Factor Chassis
  • Wireless AC, with Bluetooth Module, Gigabit LAN
  • Up to 6GB Discrete Video Card
  • Microsoft Windows 10 Operating System



Specification

Processors

Support for 10th and 11th Gen Intel® Core™ i3, i5 and i7 processor series in an LGA1150 socket

Supports Intel® Celeron™ Processor and Intel® Pentium™ Processor

Core Chipset

Intel® H510 Express Chipset

Operating System

Supports Microsoft Windows 10 Home and Professional; 64 bit

System Memory

Two DDR4 SDRAM Dual Inline Memory Module (DIMM) sockets

Support for up to DDR4 2666/2933 MHz  ; Support for up to 64 GB of system memory

Graphics

Integrated Intel® HD graphics engine

Optional Discrete Graphic Card

Hard Drive

Up to 14TB Serial ATA 6Gb/s Hard Drive

Up to 2TB M.2 NVME SSD

Up to 4TB SATA 6Gb/s SSD Solid State Drive

Supports Dual Drive ( 3.5inch and 2.5inch)

Media Storage

Optional 8x DVD Writer Drive

Built in Media Card Reader

Audio

Intel® High Definition Audio (Intel® HD Audio)

Peripheral Interfaces

Two Super Speed USB 3.0 front and Two USB 3.1 Gen 1 Rear ports; Four USB 2.0 Rear Ports

VGA Port and HDMI Port; PS2Port, Audio Ports, Gigabit Network Port

Monitors

Choice of Xitrix® Branded Flat Panel LED Display

Slots

1 X PCI Express X16 Gen 3.0 slot(s); 1 X PCI Express X 1 Gen 3.0 slot(s); 1 X M.2 2260/2280 Storage Slot

LAN Support

(10/100/1000 Mb/s) LAN subsystem Gigabit Ethernet Controller

Optional Intel® Dual Band Wireless-AC 3165 with Dual Mode Bluetooth®4.2 BLE

Chassis Type

Dimension

Power Supply

Xitrix SFF Small Form Factor 8L Chassis
Xitrix CFF Compact Form Factor Chassis

320x 163x 285mm (15L Design)

300Watts High Efficiency 80Plus Power Supply

Pre-installed

Microsoft Office 2019 30 Days Trial , Free Factory Installed Microsoft Security Essentials

Accessories

Xitrix Multimedia Keyboard and Optical Scroll Mouse

Standard Warranty and Service Offerings

Service Offerings 3-Year Limited Parts Warranty & Technical Support Policy; 1-Year Next Business Day On-site Service

Optional 3 Years Next Business Day on-site


Services
 Standard Warranty and Service Offerings
  • Service Offerings 3-Year Limited Parts Warranty & Technical Support Policy; 1-Year Next Business Day On-site Service
    Optional 3 Years Next Business Day on-site


Downloads
Title Date Filename
E-300C Product Brochure Data Sheet OS: Adobe Acrobat Reader Feb 2022 Deskframe-E300C.pdf Download
E-300C Setup Guide Data Sheet OS: Adobe Acrobat Reader Feb 2022 Deskframe-E300-CFF_setup-guide.pdf Download



Driver Name

OS (Operating System) Description
DeskFrame E-300 Windows 10 64Bit Chipset Download
DeskFrame E-300 Windows 10 64Bit ME Download
DeskFrame E-300 Windows 10 64Bit LAN Download
DeskFrame E-300 Windows 10 64Bit AUDIO Download
DeskFrame E-300 Windows 10 64Bit VIDEO Download
DeskFrame E-300 Windows 10 64Bit VIDEO GT710 Download
