Supported Processors |
Intel® Core™ Ultra 7 processor 155H 24M Cache, up to 4.80 GHz ( 16 Cores / 22 Threads) Intel® Core™ Ultra 5 processor 125H 18M Cache, up to 4.50 GHz ( 14 Cores / 18 Threads) |
|
|
Display Size |
16.0” (40.64cm) QHD+ (2560x1600)16:10 panel, 4.6mm 16.0” FHD+ (1920x1200) 16:10 panel, 4.6mm |
|
|
Operating System |
Microsoft® Windows® 11 Home or Professional 64bit; Supports Windows 10 |
|
|
System Memory |
Dual channel DDR5; Two 262 pins SODIMM sockets, support Up to DDR5 5600MHz Expandable memory up to 64GB, depends on 8GB/16GB/32GB SODIMM module |
|
|
Storage |
Up to 4TB NVME M.2 SSD Gen 3 and Gen 4 Two M.2 2280 SSD, PCIe Gen4x4 interface (RAID 0/1) |
|
|
Graphics |
Integrated Intel® Arc graphics - Ray Tracing - Variable Rate Shading - Microsoft DirectX® 12 compatible - Intel® DLBoost: DP4A |
NVIDIA® GeForce RTX™ 4050 Laptop GPU - Boost Clock 2295 MHz - Maximum Graphics Power 100W - 6GB GDDR6 Video RAM - Microsoft DirectX® 12 compatible - GeForce CUDA™ technology |
|
Connectivity |
Built in 10/100/1000Mb Base-TX Ethernet LAN Built in Intel® Dual Band Wi-Fi 6E AX211 2x2 AX + Bluetooth 5.3; CNVi M.2 2230 Built in 1.0M HD video camera; (Factory Option) 2.0M FHD camera with TNR (Temporal Noise Reduction) (Factory Option) LTE M.2 module 3042 (Factory Option) Intel® Tri-Band Wi-Fi 7 BE200 2x2 BE + BT PCIe M.2 2230 (Factory Option) Dual Sensor 2.0M FHD Hello Camera with TNR with SecureBIO |
|
|
Audio |
• Integrated Sound Blaster Studio+ High Definition Audio • Built in Array microphone, Built in two speakers(2W) |
|
|
Peripheral Interfaces |
•1 x Thunderbolt 4 combo port with Power Delivery DC in (Type C) •1 x DisplayPort 1.4 over USB 3.2 Gen 2 port (Type C) •1 x USB 3.2 Gen2 (Type A) •1 x USB 3.2 Gen1 (Type A) (1x powered USB port, AC/DC) •1 x HDMI output port (with HDCP) •1 x 2-in-1 Audio Combo Jack (Headphone / Microphone) •1 x RJ-45 LAN port, 1 x DC-in jack |
|
|
Keyboard and Pointing Device |
•Multi languages Multi-Color illuminated full size keyboard with numeric pad •Built in Click pad with Microsoft PTP multi-gesture and scrolling function |
|
|
Power |
•Full Range AC adapter, AC in 100~240V, 50~60Hz, DC output 20V/9A, 180W •Embedded 4 cells Polymer battery pack, 80WH •Battery life : 1080 minutes (UMA mode with 80WH battery) (TBC) |
|
|
Dimension |
358 (W) x 258.6 (D) x 19.9 (H) mm 1.85 kg, Including 80WH Battery |
|
|
Standard Warranty and Service Offerings |
Service Offerings 1-Year Limited Parts Warranty & Technical Support Policy; 1-Year Next Business Day On-site Service Optional 3 Years Extended Warranty with 3 Years Next Business Day Onsite |
|
Services
Standard Warranty and Service Offerings
|
Downloads
| Title | Date | Filename | |
| E16 Product Brochure Data Sheet OS: Adobe Acrobat Reader | Jan, 2024 | TravelPro-E16.pdf | Download |
