| Model |
XPN-WFP2215 |
| Size |
21.5″ |
| Panel |
Full HD IPS Panel |
| Display scale |
16:9 |
| Backlight |
ELED edge Type |
| Maximum resolution |
1920×1080; 60Hz / 75Hz |
| Pixel Pitch |
0.24795 (H) x 0.24795 (V) |
| Active Area |
476.64mm×267.786mm |
| Viewing angle |
H:178º,V:178º（CR>10） |
| Brightness |
Typ:250cd/m2 |
| Contrast ratio |
Typ:1000：1; Dynamic Contrast |
| Response time |
5ms |
| Display Colors |
16.7m |
| Color Gamut(NTSC) |
Typ:72% |
| Input Interface |
VGA Port, HDMI Port, PC Audio and Earphone port |
| Non Flash Screen |
Support（DC Adjust） |
| Blue-light filtering |
Support Blue-light filtering |
| Mode |
BCE1-24 |
| Vesa Support |
Support |
| product size(without base) |
550×324.5×31.6mm（Thinnest：8.5mm） |
| product size(with base) |
620×470×100mm |
| Power Management |
| Power input |
DC 12V/3A |
| Working consumption |
≤36W |
| Standby consumption |
≤0.5W |
| Audio power(Optional） |
2*2W |
| Safety |
| Withstand voltage strength |
≤10mA @3.0KV AC/60S |
| Leakage current |
≤3.5mA @264V AC/60S |
| Earthing protective resistance |
≤100mΩ |
| Working condition |
Temperature：5℃～40℃ humidity：10%～85% atmosphere：86KPa～104KPa |
| Storage condition |
Temperature：-20℃～55℃ humidity：5%～95% atmosphere：86kPa～104kPa |
| Warranty |
3 Years Standard Warranty |
